| virtual bool | send_to_interface (const PacketBuffer &data, const PacketMetaData &meta_data)=0 |
| | Method to be implemented by child classes to send data to the interface.
|
| |
| size_t | get_max_packet_size () const |
| | The largest packet this layer accepts; fixed when the layer is constructed.
|
| |
| virtual size_t | get_send_capacity () const |
| | How many packets send_to_interface() would accept now, so a layer above can tell before sending a series.
|
| |
| uint8_t | get_capabilities () const |
| | The capabilities of this layer and every layer below it.
|
| |
| bool | has_capability (Capability capability) const |
| |
| template<typename F > |
| void | add_on_session_state_callback (F &&callback) |
| | With CAPABILITY_SESSION, the callback is called with true when the peer can be reached, including after it restarts, and with false when it is lost.
|
| |
| PacketInterface * | top () |
| | The topmost layer stacked on this one, or this one if nothing is stacked on it.
|
| |
| void | set_name (const char *name) |
| | Name shown in log messages; a layer takes the name of the link it is stacked on.
|
| |
| const char * | get_name () const |
| |
| template<typename F > |
| void | add_packet_interface_listener (F &&callback) |
| | Add a listener that will be called when data is received.
|
| |
| void | dump_config () override |
| |
| virtual void | setup () |
| | Where the component's initialization should happen.
|
| |
| virtual void | loop () |
| | This method will be called repeatedly.
|
| |
| virtual float | get_setup_priority () const |
| | priority of setup().
|
| |
| float | get_actual_setup_priority () const |
| |
| void | set_setup_priority (float priority) |
| |
| void | call () |
| |
| virtual void | on_shutdown () |
| |
| virtual void | on_safe_shutdown () |
| |
| virtual bool | teardown () |
| | Called during teardown to allow component to gracefully finish operations.
|
| |
| virtual void | on_powerdown () |
| | Called after teardown is complete to power down hardware.
|
| |
| uint8_t | get_component_state () const |
| |
| void | reset_to_construction_state () |
| | Reset this component back to the construction state to allow setup to run again.
|
| |
| bool | is_in_loop_state () const |
| | Check if this component has completed setup and is in the loop state.
|
| |
| bool | is_idle () const |
| | Check if this component is idle.
|
| |
| void | mark_failed () |
| | Mark this component as failed.
|
| |
| void | mark_failed (const LogString *message) |
| |
| void | disable_loop () |
| | Disable this component's loop.
|
| |
| void | enable_loop () |
| | Enable this component's loop.
|
| |
| void | enable_loop_soon_any_context () |
| | Thread and ISR-safe version of enable_loop() that can be called from any context.
|
| |
| bool | is_failed () const |
| |
| bool | is_ready () const |
| |
| virtual bool | can_proceed () |
| |
| bool | status_has_warning () const |
| |
| bool | status_has_error () const |
| |
| void | status_set_warning () |
| |
| void | status_set_warning (const char *message) |
| |
| void | status_set_warning (const LogString *message) |
| |
| bool | status_comm_result (bool ok) |
| | Clears the warning when ok, else sets it with message (default "Communication failed"); returns ok.
|
| |
| bool | status_comm_result (bool ok, const LogString *message) |
| |
| void | status_set_error () |
| |
| void | status_set_error (const LogString *message) |
| |
| void | status_clear_warning () |
| |
| void | status_clear_error () |
| |
| | ESPDEPRECATED ("Use status_momentary_warning() without a name. Removed in 2027.5.0", "2026.11.0") void status_momentary_warning(const char *name |
| |
| void | status_momentary_warning (uint32_t length=5000) |
| | Set warning status flag and clear it after length ms.
|
| |
| void | status_momentary_warning (const LogString *message, uint32_t length=5000) |
| |
| | ESPDEPRECATED ("Use status_momentary_error() without a name. Removed in 2027.5.0", "2026.11.0") void status_momentary_error(const char *name |
| |
| void | status_momentary_error (uint32_t length=5000) |
| | Set error status flag and clear it after length ms.
|
| |
| void | status_momentary_error (const LogString *message, uint32_t length=5000) |
| |
| bool | has_overridden_loop () const |
| |
| const LogString * | get_component_log_str () const ESPHOME_ALWAYS_INLINE |
| | Get the integration where this component was declared as a LogString for logging.
|
| |
| bool | should_warn_of_blocking (uint32_t blocking_time, uint32_t &threshold_ms_out) |
| |
|
| | PacketInterface (size_t max_packet_size) |
| |
| virtual | ~PacketInterface ()=default |
| |
| void | on_receive_from_interface_ (const PacketBuffer &data, const PacketMetaData &meta_data) |
| | This function should be called by implementing classes with received data to be passed to any listeners.
|
| |
| void | note_received_ (bool understood) |
| | Called by a layer for each received packet it understood, or could not make sense of.
|
| |
| void | stack_on_ (PacketInterface *lower, Capability capability) |
| | Called by a layer's constructor to record itself as the layer above lower, adding its own capability.
|
| |
| void | inherit_from_ (PacketInterface *lower, Capability capability) |
| | Takes the name and capabilities of lower without becoming its top, for one of several stacks on a link.
|
| |
| friend | void::setup () |
| |
| friend | void::original_setup () |
| |
| void | set_component_source_ (uint8_t index) |
| | Set where this component was loaded from for some debug messages.
|
| |
| virtual void | call_setup () |
| |
| void | call_dump_config_ () |
| |
| void | enable_loop_slow_path_ () |
| |
| void | set_component_state_ (uint8_t state) |
| | Helper to set component state (clears state bits and sets new state)
|
| |
| bool | set_status_flag_ (uint8_t flag) |
| | Helper to set a status LED flag on both this component and the app.
|
| |
| bool | set_error_flag_ (const LogString *message) |
| | Set the error flag and log it; true when it was not set before.
|
| |
| void | set_interval (const char *name, uint32_t interval, std::function< void()> &&f) |
| | Set an interval function with a const char* name.
|
| |
| void | set_interval (uint32_t id, uint32_t interval, std::function< void()> &&f) |
| | Set an interval function with a numeric ID (zero heap allocation).
|
| |
| void | set_interval (InternalSchedulerID id, uint32_t interval, std::function< void()> &&f) |
| |
| void | set_interval (uint32_t interval, std::function< void()> &&f) |
| |
| bool | cancel_interval (const char *name) |
| | Cancel an interval function.
|
| |
| bool | cancel_interval (uint32_t id) |
| |
| bool | cancel_interval (InternalSchedulerID id) |
| |
| void | set_timeout (const char *name, uint32_t timeout, std::function< void()> &&f) |
| | Set a timeout function with a const char* name.
|
| |
| void | set_timeout (uint32_t id, uint32_t timeout, std::function< void()> &&f) |
| | Set a timeout function with a numeric ID (zero heap allocation).
|
| |
| void | set_timeout (InternalSchedulerID id, uint32_t timeout, std::function< void()> &&f) |
| |
| void | set_timeout (uint32_t timeout, std::function< void()> &&f) |
| |
| bool | cancel_timeout (const char *name) |
| | Cancel a timeout function.
|
| |
| bool | cancel_timeout (uint32_t id) |
| |
| bool | cancel_timeout (InternalSchedulerID id) |
| |
| void | defer (const char *name, std::function< void()> &&f) |
| | Defer a callback to the next loop() call with a const char* name.
|
| |
| void | defer (std::function< void()> &&f) |
| | Defer a callback to the next loop() call.
|
| |
| void | defer (uint32_t id, std::function< void()> &&f) |
| | Defer a callback with a numeric ID (zero heap allocation)
|
| |
| bool | cancel_defer (const char *name) |
| | Cancel a defer callback using the specified name, name must not be empty.
|
| |
| bool | cancel_defer (uint32_t id) |
| |
| void | status_clear_warning_slow_path_ () |
| |
| void | status_clear_error_slow_path_ () |
| |
A class that will transport data to and from an abstract channel.
The operations defined are:
Transmit: the function send_to_interface() takes a PacketBuffer of bytes, and returns when all data is written or buffered for transmission.
Receive: The callbacks for an instance of this class are called with currently received data.
Definition at line 56 of file packet_interface.h.
template<typename F >
| void esphome::packet_interface::PacketInterface::add_on_session_state_callback |
( |
F && | callback | ) |
|
|
inline |
With CAPABILITY_SESSION, the callback is called with true when the peer can be reached, including after it restarts, and with false when it is lost.
The session layer is always the top layer, so register on top(). A reliability layer calls it with false when it resets the link and discards data, which the session layer above reports as the session lost.
Definition at line 81 of file packet_interface.h.
Public Member Functions inherited from esphome::Component
