esphome::infrared::InfraredCall Class Reference

InfraredCall - Builder pattern for transmitting infrared signals. More...

#include <infrared.h>

Public Member Functions
	InfraredCall (Infrared *parent)
InfraredCall &	set_carrier_frequency (uint32_t frequency)
	Set the carrier frequency in Hz.
InfraredCall &	set_raw_timings (const std::vector< int32_t > &timings)
	Set the raw timings (positive = mark, negative = space) Note: The timings vector must outlive the InfraredCall (zero-copy reference)
InfraredCall &	set_raw_timings_packed (const uint8_t *data, uint16_t length, uint16_t count)
	Set the raw timings from packed protobuf sint32 data (zero-copy from wire) Note: The data must outlive the InfraredCall.
InfraredCall &	set_repeat_count (uint32_t count)
	Set the number of times to repeat transmission (1 = transmit once, 2 = transmit twice, etc.)
void	perform ()
	Perform the transmission.
const optional< uint32_t > &	get_carrier_frequency () const
	Get the carrier frequency.
const std::vector< int32_t > &	get_raw_timings () const
	Get the raw timings (only valid if set via set_raw_timings, not packed)
bool	has_raw_timings () const
	Check if raw timings have been set (either vector or packed)
bool	is_packed () const
	Check if using packed data format.
const uint8_t *	get_packed_data () const
	Get packed data (only valid if set via set_raw_timings_packed)
uint16_t	get_packed_length () const
uint16_t	get_packed_count () const
uint32_t	get_repeat_count () const
	Get the repeat count.

Protected Attributes
uint32_t	repeat_count_ {1}
Infrared *	parent_
optional< uint32_t >	carrier_frequency_
const std::vector< int32_t > *	raw_timings_ {nullptr}
const uint8_t *	packed_data_ {nullptr}
uint16_t	packed_length_ {0}
uint16_t	packed_count_ {0}

Detailed Description

InfraredCall - Builder pattern for transmitting infrared signals.

Definition at line 25 of file infrared.h.

Constructor & Destructor Documentation

InfraredCall()

esphome::infrared::InfraredCall::InfraredCall ( Infrared * parent )

inlineexplicit

Definition at line 27 of file infrared.h.

Member Function Documentation

get_carrier_frequency()

const optional< uint32_t > & esphome::infrared::InfraredCall::get_carrier_frequency ( ) const

inline

Get the carrier frequency.

Definition at line 44 of file infrared.h.

get_packed_count()

uint16_t esphome::infrared::InfraredCall::get_packed_count ( ) const

inline

Definition at line 54 of file infrared.h.

get_packed_data()

const uint8_t * esphome::infrared::InfraredCall::get_packed_data ( ) const

inline

Get packed data (only valid if set via set_raw_timings_packed)

Definition at line 52 of file infrared.h.

get_packed_length()

uint16_t esphome::infrared::InfraredCall::get_packed_length ( ) const

inline

Definition at line 53 of file infrared.h.

get_raw_timings()

const std::vector< int32_t > & esphome::infrared::InfraredCall::get_raw_timings ( ) const

inline

Get the raw timings (only valid if set via set_raw_timings, not packed)

Definition at line 46 of file infrared.h.

get_repeat_count()

uint32_t esphome::infrared::InfraredCall::get_repeat_count ( ) const

inline

Get the repeat count.

Definition at line 56 of file infrared.h.

has_raw_timings()

bool esphome::infrared::InfraredCall::has_raw_timings ( ) const

inline

Check if raw timings have been set (either vector or packed)

Definition at line 48 of file infrared.h.

is_packed()

bool esphome::infrared::InfraredCall::is_packed ( ) const

inline

Check if using packed data format.

Definition at line 50 of file infrared.h.

perform()

void esphome::infrared::InfraredCall::perform

(

)

Perform the transmission.

Definition at line 38 of file infrared.cpp.

set_carrier_frequency()

InfraredCall & esphome::infrared::InfraredCall::set_carrier_frequency

(

uint32_t

frequency

)

Set the carrier frequency in Hz.

Definition at line 14 of file infrared.cpp.

set_raw_timings()

InfraredCall & esphome::infrared::InfraredCall::set_raw_timings

(

const std::vector< int32_t > &

timings

)

Set the raw timings (positive = mark, negative = space) Note: The timings vector must outlive the InfraredCall (zero-copy reference)

Definition at line 19 of file infrared.cpp.

set_raw_timings_packed()

InfraredCall & esphome::infrared::InfraredCall::set_raw_timings_packed	(	const uint8_t *	data,
		uint16_t	length,
		uint16_t	count )

Set the raw timings from packed protobuf sint32 data (zero-copy from wire) Note: The data must outlive the InfraredCall.

Definition at line 25 of file infrared.cpp.

set_repeat_count()

InfraredCall & esphome::infrared::InfraredCall::set_repeat_count

(

uint32_t

count

)

Set the number of times to repeat transmission (1 = transmit once, 2 = transmit twice, etc.)

Definition at line 33 of file infrared.cpp.

Field Documentation

carrier_frequency_

optional<uint32_t> esphome::infrared::InfraredCall::carrier_frequency_

protected

Definition at line 61 of file infrared.h.

packed_count_

uint16_t esphome::infrared::InfraredCall::packed_count_ {0}

protected

Definition at line 67 of file infrared.h.

packed_data_

const uint8_t* esphome::infrared::InfraredCall::packed_data_ {nullptr}

protected

Definition at line 65 of file infrared.h.

packed_length_

uint16_t esphome::infrared::InfraredCall::packed_length_ {0}

protected

Definition at line 66 of file infrared.h.

parent_

Infrared* esphome::infrared::InfraredCall::parent_

protected

Definition at line 60 of file infrared.h.

raw_timings_

const std::vector<int32_t>* esphome::infrared::InfraredCall::raw_timings_ {nullptr}

protected

Definition at line 63 of file infrared.h.

repeat_count_

uint32_t esphome::infrared::InfraredCall::repeat_count_ {1}

protected

Definition at line 59 of file infrared.h.

---

The documentation for this class was generated from the following files:

• esphome/components/infrared/infrared.h
• esphome/components/infrared/infrared.cpp
